Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer (Battery and Charger Sold Separately)
It is ideal for indoor construction and renovation projects but also suitable for use in poorly ventilated areas, including trenches and sound-sensitive regions, such as hospitals. It is convenient to operate with a quick push-button start and easy to guide along walls. The battery is separate from the rammer and can be replaced quickly without special tools.
Features
- Emission-free compaction in trenches, industrial buildings, and enclosures!
- Suitable for all traditional soil and asphalt compaction work, protecting the operator and the environment in the process
- Easy start at the push of a button, even in very low temperatures
- Same compaction performance as comparable gasoline or diesel-powered rammers
- Low hand-arm vibrations (HAV) thanks to the parallel guidance of the handle
- The maintenance-free asynchronous electric motor was developed and produced in-house
- It can be used for all applications on an average workday with just one battery charge
- Low hand-arm vibrations
- A battery is required to operate this vibratory plate; battery and battery chargers are sold separately.
Highlights
- Large stroke, high impact force
- Just one lever for starting, idling and stopping
- Efficient air filter
- Ergonomic guide handle
- Low oil warning indicator
| OPERATING FLUIDS | Metric | Imperial |
| Oil volume | 0,700 l | 0,185 gal US |
| Oil specification | SAE 10W-40 | SAE 10W-40 |
| ENGINE | Metric | Imperial | ||
| Fuel management | Carburettor | Carburettor | ||
| Engine operating mode | four-stroke | four-stroke | ||
| Operating Engine speed | 3.950 1/min | 3.950 1/min | ||
| Fuel consumption | 0,75 kg/h | 1,00 L/Std | 1,7 lb/h | 0,3 GPH US |
| CO2 (NRSC) | 674,00 g/KWh | 674,00 g/KWh | ||
| Standard (Power max.) | SAE J1349 | SAE J1349 | ||
| Standard (Effective power) | SAE J1349 | SAE J1349 | ||
| Tank capacity | 3,00 l | 0,8 gal US | ||
| Nominal Engine speed | 3.600 1/min | 3.600 1/min | ||
| Oil filling max. | 0,30 l | 0,1 gal US | ||
| Effective power | 2,7 kW, 2,3 kW | 3,6 hp, 3,1 hp | ||
| Cooling | air cooling | air cooling | ||
| Exhaust-gas limit | US Phase 3, EU Stage V, China Stage 2 | US Phase 3, EU Stage V, China Stage 2 | ||
| Oil specification | SAE 10W-40 | SAE 10W-40 | ||
| Starter type | Recoil starter | Recoil starter | ||
| Upper idling speed ex load | 1.850 1/min | 1.850 1/min | ||
| Operating power | 2,7 kW | 3,6 hp | ||
| Engine type | Gasoline engine | Gasoline engine | ||
| Cylinder | 1 | 1 | ||
| Engine Manufacturer | Honda | Honda | ||
| Standard (Operating power) | ISO 3046-1 | ISO 3046-1 | ||
| Cylinder capacity | 121 cm3 | 7,4 Inch3 | ||
| Spark plug(s) | DENSO U16FSR-UB, NGK CR5HSB | DENSO U16FSR-UB, NGK CR5HSB | ||
| Kraftstofftyp | Gasoline | Gasoline | ||
| Engine Designation | GXR120RT-KR-W1-SD | GXR120RT-KR-W1-SD |
| MECHANICAL - OUTPUT DETAILS | Metric | Imperial |
| Forward running | 12,00 m/min | 0,7 fps |
| Power of impact | 17 kN | 3.821,8 lbf |
| Number of blows | 689 1/min | 689 1/min |
| ELECTRICAL SYSTEM | Metric | Imperial |
| Display Equipment | Beacon | Beacon |
| Electrode distance | 0,60 - 0,70 mm | 0,024 - 0,028 " |
| Operating elements | Pushbutton OFF | Pushbutton OFF |
| ENVIRONMENT DATA | Metric | Imperial |
| Operating temperature range | -10 - 40 °C | 14 - 104 °F |
| Sound level LpA (Standard) | EN 500-4 | EN 500-4 |
| Sound power LWA, guaranteed | 108,0 dB(A) | 108,0 dB(A) |
| Storage temperature range | -30 - 50 °C | -22 - 122 °F |
| HAV summation (average value) | 10,0 m/s2 | 32,8 ft/s2 |
| Uncertainty in measurement HAV | 1,0 m/s2 | 3,3 ft/s2 |
| HAV summation (Standard) | EN 500-4 | EN 500-4 |
| Sound level LpA | 91,0 dB(A) | 91,0 dB(A) |
| Sound power LWA (Standard) | EN 500-4 | EN 500-4 |
| Sound power LWA, measured | 103,0 dB(A) | 103,0 dB(A) |
| MECHANICAL DETAILS | Metric | Imperial |
| Operating weight | 64,0 kg | 141,1 lb |
| Length | 662 mm | 26,1 " |
| Length Ramming Shoe | 340 mm | 13,4 " |
| Height | 920 mm | 36,2 " |
| Width Ramming Shoe | 280 mm | 11,0 " |
| Width | 347 mm | 13,7 " |
| Weight | 63,30 kg | 139,55 lb |
| Stroke at tamper | 68 mm | 2,7 " |
Discover the Power and Efficiency of the Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer (Battery and Charger Sold Separately) Jumping Jack Tamping Rammer Compactor
In today’s construction landscape, contractors and builders are under pressure to deliver top-quality compaction, reduce downtime, and meet growing environmental standards. Enter the Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer Jumping Jack Tamping Rammer Compactor — an innovative tool designed for modern job sites that demand power, sustainability, and lower noise levels.
This comprehensive guide explores why the AS60e is transforming compaction projects, what makes it unique, its specifications, key benefits, and why it's the smarter choice for both your business and the planet.
What is the Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer?
The Wacker Neuson AS60e is a cutting-edge, battery-powered jumping jack tamping rammer compactor engineered to replace traditional gas-powered rammers. With its 11 x 13-inch shoe, it’s perfect for deep, targeted compaction in narrow trenches, utility projects, and backfilling operations.
This machine is powered by Wacker Neuson’s proven BP1000 lithium-ion battery system, known for fast swapping and reliable performance. Unlike conventional models, the AS60e produces zero local emissions, dramatically less noise, and requires fewer maintenance hours — helping contractors meet modern jobsite standards and client expectations.
Why Choose the Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer?
✅ Zero local emissions – makes it ideal for confined spaces, urban projects, and indoor work
✅ Quiet operation – reduces noise complaints and creates a safer work environment
✅ Powerful compaction – matches the performance of traditional gas-powered rammers
✅ Lower total cost of ownership – saves on fuel, oil changes, and engine maintenance
✅ Flexible battery system – quick swap batteries keep you running all day
✅ 11 x 13-inch shoe – delivers deeper, wider compaction for challenging soils
✅ Battery and charger sold separately – allowing contractors to customize power options for project needs
In today’s competitive environment, the AS60e combines sustainability, power, and flexibility — keeping crews efficient without sacrificing results.
Key Features of the Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer
1. Proven BP1000 Lithium-Ion Battery Technology
Wacker Neuson’s modular BP1000 battery system delivers steady power and offers quick swapping. Key benefits:
-
Zero fuel storage risk
-
Consistent compaction performance until the battery is empty
-
Lightweight design for easy transport
-
Long battery life with proper care
Note: The battery and charger are sold separately, giving contractors the flexibility to buy exactly what they need.
2. High-Performance Electric Drive
Engineered to deliver up to 680 impacts per minute, the AS60e easily compacts cohesive soils and granular materials, making it ideal for trench backfills, utility repairs, and landscaping.
3. Versatile 11 x 13-inch Shoe
The larger compaction shoe covers more area while still fitting into most trench sizes, ensuring deep, uniform compaction — reducing passes and saving time.
4. Quieter Operation
Operating at significantly lower noise levels than gas-powered models, the AS60e protects workers' hearing and keeps neighbors happy on residential or city-center projects.
5. Environmentally Friendly Design
With no exhaust fumes, the AS60e is safe for indoor use and meets stricter environmental standards demanded by government projects and eco-conscious clients.
Technical Specifications at a Glance
| Feature | Specification |
|---|---|
| Power source | BP1000 lithium-ion battery (sold separately) |
| Shoe size | 11 x 13 inches (280 x 330 mm) |
| Operating weight | ~154 lbs (70 kg) |
| Percussion rate | ~680 impacts/minute |
| Max compaction depth | Comparable to gas rammers (~20–30 cm depending on soil) |
| Emissions | Zero local emissions |
| Runtime | ~45–60 minutes per battery (depends on soil and load) |
| Charge time | ~80 minutes per battery |
Applications: Where the AS60e Excels
The Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer Jumping Jack Tamping Rammer Compactor shines in:
-
Utility trench work: Compacting around pipes, cables, and narrow trenches
-
Urban and residential projects: Reduced noise and zero exhaust help avoid complaints
-
Indoor construction: Basements, parking garages, tunnels, or renovations
-
Confined spaces: Projects where air quality is critical and ventilation is limited
-
Green-certified builds: Helping contractors meet LEED and sustainable building requirements
Benefits of Using the AS60e Battery-Powered Rammer
✅ Zero Local Emissions Protect Workers and the Environment
No exhaust gases mean healthier air for operators, less environmental impact, and compliance with strict local codes.
✅ Lower Operating Costs Over Time
Without gasoline, oil changes, or carburetor adjustments, contractors save on regular maintenance — plus no downtime waiting for parts.
✅ Quieter Worksites
A must for city projects, hospitals, schools, or early morning and nighttime construction work.
✅ Powerful, Consistent Compaction
Delivers the same reliable performance as gas-powered models, ensuring strong, even soil compaction.
✅ Better Flexibility
Since the battery and charger are sold separately, crews can buy multiple batteries to match project demands, keeping teams moving even on longer shifts.
Practical Tips for Contractors
-
Buy extra batteries: Keep spare BP1000 batteries on site for seamless shifts.
-
Protect your batteries: Avoid direct sun, moisture, and extreme temperatures.
-
Match shoe size to project: The 11 x 13" shoe is versatile, but for extremely tight trenches, narrower options may be available.
-
Train operators: Electric rammers feel slightly different from gas-powered ones — a short learning curve helps maximize efficiency.
-
Maintain cleanliness: Regularly remove dirt and debris from the compactor and battery contacts.
Maintenance Tips for the AS60e
-
Clean shoe and guide components daily
-
Wipe battery contacts with a dry cloth
-
Inspect rubber mounts for cracks or wear
-
Charge batteries after use and store in a cool, dry area
-
Follow Wacker Neuson’s maintenance schedule to protect your investment
Why Wacker Neuson Leads in Compaction
With over 90 years of experience, Wacker Neuson is synonymous with innovation and reliability in construction equipment. The AS60e reflects this legacy, offering contractors:
-
Rugged, field-tested equipment built for real job sites
-
Dependable dealer network for parts and service
-
Cutting-edge technology like the BP1000 modular battery system
-
Proven durability and resale value
Why the Battery and Charger are Sold Separately
This approach benefits contractors by:
-
Customizing power supply: Buy the exact number of batteries you need for each crew
-
Reducing cost: Skip extra batteries if your projects are shorter
-
Future compatibility: Use the same BP1000 battery across other Wacker Neuson electric models
-
Lower shipping and storage concerns: Batteries are often shipped separately due to safety regulations
Conclusion: The Future is Battery-Powered with the Wacker Neuson AS60e 11 x 13" Rammer
The Wacker Neuson AS60e 11 x 13" Battery-Powered Rammer Jumping Jack Tamping Rammer Compactor isn’t just an eco-friendly alternative — it’s a powerful, reliable, and cost-effective choice for modern contractors.
With zero local emissions, quieter operation, and lower long-term costs, the AS60e empowers your team to work smarter, comply with environmental standards, and deliver quality results every time.
Make your projects greener, safer, and more productive with the Wacker Neuson AS60e — a truly next-generation solution for serious compaction.
